Name: KQS-WSM Mini Integrated Weather Station with 5-in-1 Sensor IP64 Protection and Low Power Consumption
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KQS-WSM
Price: 5,000.00 USD
Availability: InStock

Dom > produkty > Environmental Monitoring >

KQS-WSM Mini Integrated Weather Station with 5-in-1 Sensor IP64 Protection and Low Power Consumption

Miejsce pochodzenia:

Chiny

Nazwa handlowa:

KunQuan

Orzecznictwo:

Numer modelu:

KQS-WSM

Skontaktuj się z nami

Poproś o wycenę

KQS-WSM Mini Integrated Weather Station with 5-in-1 Sensor IP64 Protection and Low Power Consumption

Szczegóły produktu

Typ czujnika:

Zintegrowany 5 w 1 (wiatr, temperatura, wilgotność, ciśnienie)

Waga:

240 gr

Wymiary:

Wysokość ~17 cm, maks. śr. ~10cm

Zużycie energii:

< 150 mW Razem

Ocena ochrony:

IP64

Komunikacja:

RS485/RS232/TTL (Modbus-RTU)

Warunki płatności i wysyłki

Minimalne zamówienie

1 szt

Szczegóły pakowania

Każde urządzenie ma indywidualne pudełko, a wszystkie pola są pakowane w standardowe pakiety lub dos

Czas dostawy

5-8 dni roboczych

Zasady płatności

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Możliwość Supply

1000 sztuk/szt. tygodniowo do negocjacji

ZAŁĄCZONE PRODUKTY

KQS-ZSYT Fully Automatic Direct-Diffuse Integrated Radiation Monitoring Instrument with High Accuracy Dual Tracking Global Applicability and Multiple Communication Options

Najlepszą cenę

KQZ-GF Photovoltaic Weather Station with Meteorological-Grade Sensors, Fully Waterproof Design, and Customizable Mounting Pole

Najlepszą cenę

KQZ-BX Portable Weather Station with Fully Waterproof Design, Built-in Battery, and Foldable/Telescopic Structure

Najlepszą cenę

KQS-GTM Tubular Multi-layer Soil Moisture Monitoring Instrument with FDR Technology for Multi-layer Monitoring (10/20/30/40 cm) and Solar Power

Najlepszą cenę

Skontaktuj się z nami

Skontaktuj się teraz

Opis produktu

KQS-WSM Mini Integrated Weather Station

KQS-WSM Mini Integrated Weather Station

The KQS-WSM mini integrated weather station is a compact, highly integrated environmental monitoring sensor. Compared with traditional all-in-one environmental sensors, it features a smaller design while maintaining powerful functionality. It can quickly and accurately measure five meteorological parameters: wind speed, wind direction, air temperature, humidity, and atmospheric pressure.

It is widely used for environmental monitoring in agriculture, meteorology, forestry, power systems, chemical plants, ports, railways, and highways.

Technical Parameters

Measurement Item (Optional)	Range	Accuracy	Resolution	Power Consumption
Wind speed	0-45 m/s	Start wind speed ≤ 0.8 m/s, ±(0.5 + 0.02V) m/s	0.1 m/s	40 mW
Wind direction	0-359°	±3°	1°	--
Air temperature	-40-80°C	±0.3°C	0.1°C	1 mW
Air humidity	0-100% RH	±5% RH	0.1% RH	--
Atmospheric pressure	300-1100 hPa	±0.5 hPa (25°C)	0.1 hPa	0.1 mW

Total sensor power consumption: <150 mW

Power supply: DC 5V / DC 9-30V / Others optional

Communication: RS485 (Modbus-RTU) / RS232 (Modbus-RTU) / TTL (Modbus-RTU)

Cable length: Standard 2 m

Weight: 240 g

Operating environment: 0-100% RH, -40°C to +60°C

Protection rating: IP64

Product Features

Integrated design enabling simultaneous monitoring of wind speed, wind direction, temperature, humidity, and atmospheric pressure
Measurement elements can be optionally configured as 2-parameter, 4-parameter, or 5-parameter combinations based on requirements
Compact and lightweight design: height approx. 17 cm, maximum diameter approx. 10 cm, weight under 0.25 kg, easy to install
Advanced filtering algorithm with special compensation for rain and fog conditions, ensuring stable and consistent data output
Each unit is calibrated before leaving the factory using wind tunnel and high/low temperature calibration chambers, ensuring compliance with national standards
Strong environmental adaptability, tested under high/low temperature, waterproof, and salt spray conditions

Dimensions
