Name: KMPW520 Multi-Parameter Water Quality Analyzer with 7 Inch Touch Screen Display 6-Channel Relay Control and 2-Channel 4-20mA Output
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KMPW520
Price: 5,000.00 USD
Availability: InStock

Dom > produkty > Czujnik jakości wody >

KMPW520 Multi-Parameter Water Quality Analyzer with 7 Inch Touch Screen Display 6-Channel Relay Control and 2-Channel 4-20mA Output

7 inch touch screen display Water Quality Analyzer

6-channel relay control Water Quality Analyzer

2-channel 4-20mA output Water Quality Sensor

Miejsce pochodzenia:

Chian

Nazwa handlowa:

KACISE

Orzecznictwo:

Numer modelu:

KMPW520

Skontaktuj się z nami

Poproś o wycenę

KMPW520 Multi-Parameter Water Quality Analyzer with 7 Inch Touch Screen Display 6-Channel Relay Control and 2-Channel 4-20mA Output

Szczegóły produktu

Warunki pracy:

0–60 ℃, wilgotność ≤ 90%

Zasilanie:

AC 220V

Rozmiar:

223 mm × 200 mm × 120 mm

Waga:

1,51 kg

Metoda instalacji:

Instalacja naścienna

Poziom ochrony:

IP65

Podkreślić:

7 inch touch screen display Water Quality Analyzer

6-channel relay control Water Quality Analyzer

2-channel 4-20mA output Water Quality Sensor

Warunki płatności i wysyłki

Minimalne zamówienie

1 szt

Szczegóły pakowania

Każde urządzenie ma indywidualne pudełko, a wszystkie pola są pakowane w standardowe pakiety lub dos

Czas dostawy

5-8 dni roboczych

Zasady płatności

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Możliwość Supply

1000 sztuk/sztuk tygodniowo do negocjacji

ZAŁĄCZONE PRODUKTY

KWS-790 Digital pH Sensor with 0.00–14.00 pH Measuring Range ±0.02 pH Accuracy and 0–99.9 ℃ Temperature Compensation

Najlepszą cenę

KMPW520 Multi-Parameter Water Quality Analyzer with 7 Inch Touch Screen Display 6-Channel Relay Control and 2-Channel 4-20mA Output

Najlepszą cenę

TDLAS302 Laser Methane Sensor with 0.1 ppm Resolution and 0–1000 ppm Measurement Range for High Accuracy Gas Analysis

Najlepszą cenę

Ściany optyczny miernik DO z zakresem pomiaru 0,00-20,00 mg/L, dokładnością ± 2% F.S. i rozdzielczością 0,01 mg/L

Najlepszą cenę

Skontaktuj się z nami

86--17719566736

Skontaktuj się teraz

Opis produktu

KMPW520 Multi-Parameter Water Quality Analyzer

Product Configuration

Electronic Cabinet x 1
Controller × 1
Sensors for the controller
User manual

Product Introduction

The KMPW520 Multi-Parameter Water Quality Analyzer is a next-generation monitoring system featuring digital sensors for flexible parameter combinations. Designed for industrial applications, it offers comprehensive control capabilities with multiple analog and relay channels, supporting Modbus-RTU protocol for remote data transmission.

Main Features

RTOS system for enhanced performance, stability, and real-time monitoring
7-inch touch screen with English menu and multi-parameter display
6 freely configurable data channels with selectable measurement units
6-channel relay control with high/low alarm settings
2-channel 4-20mA analog output with adjustable ranges
2-channel RS-485 digital interface supporting MODBUS-RTU protocol
Sensor calibration and configuration tools including factory reset
Data logging to TF card (up to 32GB) and USB export capability
Password protection and dual interface themes
Historical data visualization with curves and records

Technical Specifications

Measurement Parameters:

Temperature, PH, ORP, conductivity, TDS, salinity, dissolved oxygen, residual chlorine, dissolved ozone, turbidity, TSS, sludge concentration, hardness, ion concentration, Resistivity, COD, BOD, etc.

Parameter Combinations:

Maximum 6 parameters in free combination (examples: PH+ORP+conductivity+DO+residual chlorine+turbidity)

Specification	Details
Power Supply	AC 220V
Dimensions	223mm × 200mm × 120mm
Weight	1.51kg
Installation	Wall-mounted
Operating Conditions	0-60℃, humidity ≤90%
Protection Level	IP65
Input Interface	6-channel RS485 with 12V power supply (1A total capacity)
Analog Output	2-channel 4-20mA (750Ω load capacity per channel)
Relay Control	6 channels (3A load capacity per channel)
Digital Output	2-channel RS485 (Modbus-RTU protocol)
Display	7.0-inch LCD (800×480 resolution), capacitive touch
